本设备属于经济型机械，主要使用于白茬的精细定尺，白茬的表面精细抛光
型号
TYPE
MSG630R-RP
MSG1000 R-RP
MSG1300 R-RP
加工宽度
Working Width
40-630mm
40-1000mm
40-1300mm
最短加工长度
Working Length
≥380mm
≥380mm
≥510mm
加工厚度
Working Thickness
2-100mm
2-100mm
2-100mm
送料速度
Feed Speed
5-25m/min
5-25m/min
5-25m/min
砂带尺寸
Size of Abrasive Belt
650*1900mm
1020*2000mm
1320*2200mm
电机总功率
Total Motor Power
20.37kw
27.87kw
56.55kw
工作气压
Working Air Pressure
≧0.55Mpa
≧0.55Mpa
≧0.55Mpa
吸尘风速
Speed of Sucked Air
≧25m/s
≧25m/s
≧25m/s
