本机型为本公司出口型机器,加重型配置。主要适用于:白茬的精确定尺,白茬表面的精细抛光。
技术参数表:
机器名称
Device name
高配置宽带砂光机
高配置宽带砂光机
高配置宽带砂光机
型号
TYPE
MSG630R-RP(A)
MSG1000R-RP(A)
MSG1300R-RP(A)
加工宽度
Working Width
40~630mm
40~1000mm
40~1300mm
加工厚度
Working Thickness
2~100mm
2~100mm
2~100mm
加工长度
Working Length
≥420mm
≥420mm
≥510mm
送料速度
Feed Speed
5~25m/min
5~25m/min
5~25m/min
电机总功率
Total Motor Power
20.37 KW
27.87 KW
56.55 KW
工作气压
WorkingAir Pressure
0.6Mpa
0.6Mpa
0.6Mpa
工作电压
Working voltage
380V,50Hz
380V,50Hz
380V,50Hz
吸尘风速
Speed of Sucked Air
8200m3/h
8200m3/h
8200m3/h
吸尘口直径
Vacuuning Mouth Diameter
∮150mm*2个
∮150mm*2个
∮150mm*2个
